Titanium Bar & Rod
Centerless Ground & Peeled High-Strength Titanium Alloy Round Bars
Available Grades
Standards
Precision ground and peeled titanium round bars with ultra-tight diameter tolerances (h7-h9) for CNC machining, aerospace fasteners, and medical orthopedic applications.
Key Dimensions
| Diameter | 2.0mm - 400mm |
| Length | 1000mm - 6000mm |
| Tolerance | h6 / h7 / h8 / h9 |
| Custom | Saw cutting available |
Description
Overview & Engineering Characteristics
BAOTI titanium bars and rods are produced from VAR double/triple melt ingots through rotary forging and radial extrusion. Available in round, square, hex, and flat profiles. Our centerless grinding capabilities achieve h6/h7 tolerance with surface roughness down to Ra 0.4um, ideal for precision aerospace fasteners, medical implant shafts, and high-performance racing engine components.
Manufacturing Process
Available Surface Finishes
Specifications
Chemical Composition (%)
| Element | Gr 2 | Gr 5 | Gr 23 |
|---|---|---|---|
| Ti (Titanium) | Balance | Balance | Balance |
| Al (Aluminum) | - | 5.5-6.75 | 5.5-6.5 |
| V (Vanadium) | - | 3.5-4.5 | 3.5-4.5 |
| Fe (Iron (max)) | 0.30 | 0.40 | 0.25 |
| O (Oxygen (max)) | 0.25 | 0.20 | 0.13 |
Mechanical Properties
Room Temp (20C / 68F)| Property | Gr 2 | Gr 5 | Gr 23 |
|---|---|---|---|
| Tensile Strength (min) (MPa) | 345 | 895 | 860 |
| Yield Strength (min) (MPa) | 275 | 828 | 790 |
| Elongation (min) (%) | 20 | 10 | 10 |
| Reduction of Area (%) | 30 | 25 | 25 |
Applications
Aerospace Fasteners
- Structural bolts and pins
- Helicopter rotor components
- Jet engine stator vanes
- Landing gear pins
Medical Prosthetics
- Spinal fusion rods
- Dental abutments
- Orthopedic bone screws
- Prosthetic limb couplers
Oil & Gas
- Downhole tool components
- Drill collar subs
- Valve stems
- High-pressure fittings
Racing & Automotive
- Connecting rods
- Exhaust valves
- Suspension springs
- Turbo shaft components
Quality & Certifications
Every batch undergoes rigorous multi-stage non-destructive and mechanical testing in our ISO 17025 accredited metallurgical laboratory. EN 10204 3.1 Mill Test Certificates (MTR) are supplied with all shipments.
Certifications & Standards
Inspection Procedures
