Precision Titanium Cutting Services — From 0.5mm Foil to 200mm Plate

Get a Quote Call Us

200mm

Max Plate Thickness

±0.1mm

Laser Tolerance

24h

Rush Turnaround

Cross-Contamination

Overview

BAOTI offers comprehensive titanium cutting services including band saw cutting, laser cutting, water jet cutting, and plasma cutting. We process plates, bars, tubes, and other titanium mill products to your exact dimensions.

Our cutting facilities handle thicknesses from 0.5mm foil to 200mm plate, with tight tolerances and clean, burr-free edges. All cutting is performed in dedicated titanium-only workshops to prevent cross-contamination.

With over 50 years of titanium processing experience, our cutting operators understand the unique thermal and mechanical properties of titanium alloys, ensuring optimal cutting parameters for every grade and thickness.

Quick Inquiry

Need cutting & cut-to-length? Get a quote within 24 hours.

Request a Quote WhatsApp Chat

24/7 Online Response

EN 10204 3.1 Certificates

Global Shipping (FOB/CIF/DDP)

Our Capabilities

Comprehensive cutting & cut-to-length solutions backed by 50+ years of titanium expertise.

Band Saw Cutting

High-precision band saw for bars, billets, and plates up to 500mm. Straight cuts with minimal kerf loss. Coolant-fed carbide blades for clean, oxide-free surfaces.

Fiber Laser Cutting

Up to 25mm thick plates. Complex 2D shapes, tight tolerances ±0.1mm, smooth dross-free edges. Nitrogen-assist for oxide-free cut faces.

Water Jet Cutting

Abrasive water jet for heat-sensitive titanium alloys. Zero heat-affected zone (HAZ), thickness up to 150mm. Ideal for Grade 5 and other alpha-beta alloys.

Plasma Cutting

HD plasma cutting for heavy plates up to 200mm. Fast processing for large-volume orders. Automated nesting for material optimization.

Shearing & Guillotine

Precision shearing for thin sheets and strips up to 6mm. Length tolerance ±1mm. High throughput for production volume.

Cut-to-Length Service

Bars, tubes, and profiles cut to exact customer specification. Bundle cutting for efficiency. Deburring and chamfering available.

Gallery

Our Process

Order Review

Confirm material grade, dimensions, tolerances, and quantity

Material Prep

Select certified stock, verify MTR and heat number traceability

Cutting

Execute cut using optimal method for grade and thickness

Inspection

Dimensional verification, surface quality check, documentation

Packaging

Clean, protect, label with full traceability, and ship

Equipment

TRUMPF TruLaser 5030

8kW fiber laser, 3m × 1.5m bed

Flow Mach 500

94,000 PSI water jet, 4m × 2m

Amada HFA-400W

Band saw, 400mm capacity

Messer OmniMat HD

Plasma, 200mm capacity

Certifications: ISO 9001:2015AS9100DEN 10204 3.1

Frequently Asked Questions

What is the maximum thickness you can laser cut?

We can laser cut titanium plates up to 25mm thick. For thicker material, we recommend water jet cutting (up to 150mm) or plasma cutting (up to 200mm).

Can you cut complex shapes from titanium plate?

Yes, our laser and water jet cutting can produce complex 2D profiles with tight tolerances. Please provide a DXF or DWG drawing file.

Do you provide material test reports for cut pieces?

Yes, all cut pieces retain full traceability to the original heat. We provide EN 10204 3.1 mill test reports with every shipment.

What is the typical lead time for cutting services?

Standard orders are processed within 3-5 business days. Rush cutting services with 24-hour turnaround are available for urgent requirements at a surcharge.

Do you offer cut-to-size titanium with no minimum order?

Yes, we accept single-piece and small-quantity cutting orders. There is no minimum order quantity for our cutting services, though pricing per cut may vary for small volumes.
