Titanium Ingots & Billets
VAR & EBCHR Melted Titanium Ingots and Forged Billets
Available Grades
Standards
Vacuum Arc Remelted and Electron Beam melted titanium ingots and forged billets as primary raw material for plate, bar, tube, and forging production.
Key Dimensions
| Ingot Diameter | 200mm - 1100mm |
| Ingot Weight | Up to 10 metric tons |
| Billet Diameter | 80mm - 400mm |
| Billet Length | Up to 6000mm |
Description
Overview & Engineering Characteristics
BAOTI is one of the world's largest producers of titanium ingots, with annual melting capacity exceeding 40,000 metric tons. Our ingots are produced via Vacuum Arc Remelting (VAR) in double or triple melt configurations, or Electron Beam Cold Hearth Remelting (EBCHR) for highest purity requirements. Billets are produced by cogging and forging ingots on our large hydraulic presses. Available in commercially pure and all major alloy grades for downstream plate, bar, tube, wire, and forging production.
Manufacturing Process
Available Surface Finishes
Specifications
Chemical Composition (%)
| Element | Gr 1 | Gr 2 | Gr 5 | Gr 9 |
|---|---|---|---|---|
| Ti (Titanium) | Balance | Balance | Balance | Balance |
| Al (Aluminum) | - | - | 5.5-6.75 | 2.5-3.5 |
| V (Vanadium) | - | - | 3.5-4.5 | 2.0-3.0 |
| Fe (Iron (max)) | 0.20 | 0.30 | 0.40 | 0.25 |
| O (Oxygen (max)) | 0.18 | 0.25 | 0.20 | 0.15 |
Mechanical Properties
Room Temp (20C / 68F)| Property | Gr 1 | Gr 2 | Gr 5 | Gr 9 |
|---|---|---|---|---|
| Tensile Strength (min) (MPa) | 240 | 345 | 895 | 620 |
| Yield Strength (min) (MPa) | 170 | 275 | 828 | 483 |
| Elongation (min) (%) | 24 | 20 | 10 | 15 |
Applications
Mill Product Feedstock
- Plate & sheet rolling
- Bar & rod forging
- Tube extrusion billets
- Wire drawing stock
Aerospace Raw Material
- Engine disc forgings
- Structural frame billets
- Landing gear blanks
- Premium aerospace quality
Medical Grade Stock
- ELI grade billets for implants
- Dental bar stock
- Surgical instrument blanks
- ISO 5832 compliant
Industrial Applications
- Chemical plant forgings
- Marine shaft blanks
- Power generation rotors
- Custom alloy melting
Quality & Certifications
Every batch undergoes rigorous multi-stage non-destructive and mechanical testing in our ISO 17025 accredited metallurgical laboratory. EN 10204 3.1 Mill Test Certificates (MTR) are supplied with all shipments.
Certifications & Standards
Inspection Procedures
Related Products
Titanium Plate & Sheet
High-quality titanium plates and sheets for demanding industrial applications. Offering excellent corrosion resistance, high strength-to-weight ratio, and biocompatibility.
Titanium Bar & Rod
Precision ground and peeled titanium round bars with ultra-tight diameter tolerances (h7-h9) for CNC machining, aerospace fasteners, and medical orthopedic applications.
Titanium Tube & Pipe
Seamless cold-drawn and ERW welded titanium tubes designed for severe corrosive environments, heat exchangers, offshore seawater cooling, and aerospace hydraulic conduits.
Titanium Wire
Ultra-clean titanium wire for TIG/MIG welding (AWS A5.16), additive manufacturing, medical sutures, and eyewear applications.
Need Custom Specifications?
Our metallurgical engineers can assist with non-standard dimensions, custom alloys, special heat treatments, and tight tolerance requirements. Send us your drawing or specification sheet.
